- Stock: 1 - 5 Days
- Cat No: CKP1206 3968
- SKU: CKP1206
- UPC: 6009515839024
Tork Craft CKP1206 Corner Round Router Bit 1/2 Inch Shank X 1/4 Inch Radius
At a Glance: 1/4 inch radius corner round router bit with 1/2 inch shank, tungsten carbide cutting edge and 1/2 inch bearing for smooth rounded woodworking edges.
The Tork Craft CKP1206 Corner Round Router Bit is designed to create clean, smooth and professional rounded edges on timber and suitable woodworking materials. With its 1/4 inch radius and stronger 1/2 inch shank, this bit is ideal for softening sharp corners on furniture parts, shelves, cabinet components, frames, trims and general woodworking projects.
The tungsten carbide cutting edge helps deliver smooth, accurate cutting performance, while the bearing-guided design follows the edge of the workpiece for a consistent rounded profile. The 1/2 inch shank provides improved stability compared to smaller shank bits, making it a practical choice for carpenters, craftsmen, hobbyists, DIY users and woodworking workshops.
The CKP1206 forms part of the Tork Craft corner round router bit range and is specifically engineered to provide smooth and accurate cutting. It is a useful finishing bit for creating a neat 1/4 inch round-over profile on edges that need a softer, cleaner and more professional finish.
Product highlights
- 1/4 inch radius Creates a neat rounded edge profile on suitable timber and woodworking materials.
- 1/2 inch shank Provides improved stability and is designed for routers fitted with a compatible 1/2 inch collet.
- Tungsten carbide cutting edge Helps provide clean cutting performance and good wear resistance.
- Bearing guided The 1/2 inch bearing helps guide the bit along the edge of the workpiece.
- Smooth edge finishing Ideal for softening sharp edges on furniture, shelving, cabinets, frames and trim work.
- Woodworking essential Suitable for carpenters, craftsmen, hobbyists, DIY users and woodworking applications.
Definition: The basic edge-forming bit, the corner-rounding bit rounds an edge to a given radius. The tool is shouldered to cut a fillet. The cut can be used to ease edges, as a simple profile, or as a part of a complex one. Also known as roundover, rounding over, and quarter-round. If a smaller pilot bearing is used, a second shoulder can be produced, in effect making the bit a beading bit.
Specifications
| Description | Spec |
|---|---|
| Brand | Tork Craft |
| Cat No. | CKP1206 |
| Barcode | 6009515839024 |
| Product Type | Corner Round Router Bit |
| Product Description | Corner Round Bit 1/2 Inch X R1/4 Inch |
| Product Classification | Standard Yellow |
| Radius | 1/4 inch |
| A Dimension | 1 inch |
| B Dimension | 1/2 inch |
| Shank Diameter | 1/2 inch |
| D Dimension | 32mm |
| Bearing | 1/2 inch |
| Cutting Edge Material | Tungsten Carbide |
| Body & Shank Material | HSS (High Speed Steel) |
| Packaging Type | Hanging Card / Blister |
| Sales Unit | Each |
| Recommended Machine | Router Machine |
| Warranty | 6 Months |
In the box / Packaging:
- 1 x Tork Craft CKP1206 Corner Round Router Bit 1/2 Inch X R1/4 Inch
- Supplied in hanging card / blister packaging
Explaining the Specifications:
- (d) -> The diameter of the shank or shaft. This size should be the same as the collet size of your router. Example: a small router is mostly supplied with a quarter inch collet that is 6,35 mm inside diameter.
- Common collet sizes:
- 1/4" collet = 6,35mm inside diameter
- 8mm collet = 8mm inside diameter
- 12mm collet = 12mm inside diameter
- 1/2" collet = 12,7mm inside diameter
- NOTE that the 12mm and the 12,7mm
(1/2") are often misunderstood and 1/4 inch is not 6mm but e
xactly
6,35mm. A 6mm shank will not fit in a 1/4 in collet. You will either
break the collet or the bit will fall out.
- (D) -> The actual width that the cutter will cut, groove, or profile.
- (B) -> The lenth of the cutting edge of the router bit
- (L) -> The total length of the router bit
- TCT = Tungsten Carbide Tipped
- Allways stay in the MAX Speed range of router bit
